Product Overview
Features
- [High Accurate and Multi scenario Design]: This handheld camera supports measuring temperatures from -40°C to +300°C, with a measurement accuracy of ±2℃. It is suitable for various applications, from home safety inspections to industrial parts inspections, meeting a variety of high precise, noncontact temperature measurement needs.
- [Convenient and Efficient Operation Experience]: The 2.8inch TFT display intuitively presents the measurement data, including the maximum, minimum, and center point temperatures. With an 8Hz dynamic refresh rate, it ensures real time measurement without delay. Equipped with 240*320 infrared pixels, it captures high resolution images and displays rich details. The high frame rate of 8Hz provides smooth, low latency temperature refresh images, helping quickly detect and diagnose subtle temperature anomalies.
- [Imaging Storage]: The device features a one button photo taking and direct U disk connection function, making it easy and quick to view and copy imaging. The built in serial peripheral interface flash chip can store up to 100 imagings, which can be viewed and copied to a PC or cellphone via a data cable. The device also effectively manages storage space with a reset function.
- [Ruggedized Design]: Compact in size and light in weight, this device is easy to carry. It adopts an FR4 sheet material housing, effectively protecting the internal precise elements to ensure long term stable operation and prolong its service lifespan. With integrated design, there's no need for additional accessories. It's plug and play, simplifying the operation process and enhancing work efficiency.
- [Long lasting Battery and Flexible Charging]: This device comes with a built in 1000mAh battery, supporting up to 4 hours of continuous operation. The use of a Type C interface ensures strong compatibility and a stable connection. It also supports charging while in use, making it especially suitable for long periods of on site operate.
- [Wide Applications]: This device excels in delivering high precise, noncontact temperature measurements, including body temperature detection, intelligent environmental temperature measurement and control within buildings, automobile maintenance inspections, automobile parts temperature detection, industrial elements temperature detection, leakage detection, and maintenance of floor heating equipment, thermal inspection of circuit board, etc.
Specifications
- This handheld camera supports measuring temperatures from -40°C to +300°C, and with a measurement accuracy of ±2°C, meeting the needs of various temperature measurements. The 2.8inch TFT display visualizes the measurement data, including the maximum, minimum, and center point temperatures. A built in serial peripheral interface flash chip can store up to 100 imagings, which can be viewed and copied to a PC or cellphone via a data cable. This device is mainly used to measure and analyze the thermal properties of various materials, energy, environment, and industrial production processes. Suitable for teaching and scientific research experiments.
- Specifications:
- Name: Thermal Imager
- Material: printed circuit board + resin plate
- Battery: 1 * 3.7V 1000mAh Liion battery (included)
- Infrared sensor: MLX90640ESF-BAB
- Hardware resolution: 32*24 px infrared array
- Screen resolution: 320*240 pixels
- Temperature measurement range: -40℃ to 300℃
- Measurement accuracy: ±2℃
- Operating temperature: 0℃ to 50℃
- Operating Humidity: ≦70%
- Refresh rate: 8Hz
- Field of view: 55° horizontal * 35° vertical
- Emissivity: 0.95
- Charging specification: Type C 5V/1A
- Operating time: ≥4 hours
- Item size: 87 * 55 * 17mm / 3.43 * 2.17 * 0.67in
- Item weight: 109g / 3.84ounce
- Package size: 126 * 104 * 42mm / 4.96 * 4.09 * 1.65in
- Package weight: 143g / 5.04ounce
Package List
- 1 * Thermal Imager
- 1 * Type C Cable
